Last march, we delivered a high-power test system, and now—we finally have photos to share!
📸 In the full setup photo, you can see:
• The two 120 kW power supplies (the two tall bays)
• The custom discharge bay, all connected and powered on to demonstrate the system in operation
🔍 The next two photos focus on the discharge bay:
• Everything is disconnected to show the interface connections
• One photo gives you a look inside the discharge bay, providing insight into what a high-power discharge resistor looks like—designed to safely dissipate the energy stored in the customer’s capacitor bank. This is a critical safety component!
This project is a collaboration with our local distributor for a German client, a leading manufacturer of high-power inverters used in electric vehicle applications. Their challenge? Scaling up their test capabilities by increasing both voltage and power levels.
#PowerElectronics #HighVoltage #Testing #Innovation #EV #Inverters #Engineering
