Electron gun systems require high-voltage and multiple low-voltage power supplies isolated at the cathode voltage, working together with exceptional precision. To meet these requirements, Technix developed a fully custom multi-output power supply for an Asian manufacturer specializing in electron gun technology.
The system integrates several dedicated power supplies into a single solution:
• Cathode power supply: 60kV – 40kW
• Filament power supply: 20V – 15A (isolated at 60kV)
• Bombardment power supply: 2.5kV – 100mA (isolated at 60kV)
• Auxiliary power supplies (all isolated at 60kV): +15V – 0.5A, -15V – 0.5A, +9V – 6A, +150V – 100mA, -100V – 30mA
A key feature of this system is the set of auxiliary power supplies, which are used to precisely control the electron beam, enabling greater beam penetration.
For more than 12 years, this customer has continued to rely on Technix for the production of these highly specialized power systems. ⚡
This long-term collaboration reflects our ability to design custom high-voltage solutions tailored to the most demanding industrial applications.
#HighVoltage #ElectronGun #PowerSupply #Engineering g#IndustrialTechnology #Innovation #CustomDesign
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
The development of new electric propulsion systems is opening exciting possibilities for future orbital transportation.
One of our customers, a french start-up working on advanced electric propulsion technologies, selected Technix power supplies to support the testing of their prototypes. Their approach combines concepts already used in fields such as particle accelerators and ion sources to explore innovative propulsion solutions for space applications.
To support their test campaigns, Technix supplied:
• 2 × 1kV – 2kW DC power supplies
• 2 × 5kV – 40kW DC power supplies
A key feature of these units is their floating high-voltage outputs, providing maximum flexibility during testing:
• Easy polarity reversal
• Isolated current return paths
• Simplified integration of measurement equipment
• Support for a wide range of experimental configurations
In research and development environments, flexibility is often just as important as performance.
Our ability to deliver these systems within a short timeframe, combined with our responsiveness throughout the project, played a key role in supporting the customer’s development program.
Another example of how high-voltage power supplies contribute to the technologies shaping tomorrow’s space industry.
#SpaceTechnology #ElectricPropulsion #SpaceResearch #HighVoltage #PowerSupply #Engineering #Innovation
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
More than 20 years ago, a leading European plasma physics research laboratory selected Technix to replace legacy high-voltage power supplies from another manufacturer.
To ensure a seamless integration into the existing installation, Technix developed several 50kV – 20kW negative DC power supplies specifically designed to meet the laboratory’s requirements, including:
• Control interfaces and functions fully compatible with the existing control system
• Positive output isolated from ground up to 2kV
• High-voltage output cable compatible with the existing infrastructure
As part of an expansion project, they have chosen to order additional power supplies compatible with the existing setup, allowing them to increase their capabilities while maintaining continuity across the installation.
This project is a great example of the importance of long-term reliability, backward compatibility, and technical collaboration in demanding research environments. ⚡
#HighVoltage #PowerSupply #PlasmaPhysics #Research #Engineering #Innovation #DCPowerSupply
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
For a North American start-up, Technix recently supplied several 20kV – 3kW DC power supplies for an innovative water recovery demonstrator.
The system is designed to capture evaporated water from the air using electrostatic fields. High voltage is used to ionize water particles, making it possible to condense and recover them efficiently.
This approach offers several advantages compared to traditional systems:
• No mechanical parts involved in the extraction process
• Improved reliability and reduced maintenance
• A simpler and more robust overall system
This type of solution is particularly relevant for industrial sites where large amounts of water vapor are released. Recovering this water helps reduce the need for environmental water extraction and limits the local impact.
Technix was selected not only for the performance of its power supplies, but also for the technical support provided throughout the project, from defining the right solution to configuration and responsiveness during key phases.
A great example of how high-voltage technology can support innovative and more sustainable applications.
#HighVoltage #PowerSupply #Innovation #WaterRecovery #Sustainability #Engineering
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
In large research facilities such as synchrotrons, generating pulses for advanced experiments requires reliable and high-energy charging systems.
Back in 2014, Technix developed 50kV – 10kJ capacitor chargers for a major European synchrotron, also used as a neutron and muon source.
These chargers are designed to operate at high voltage with continuous repetition rates above 10 Hz, delivering 10kJ/s charging power, all within a compact format. They are used to charge Pulse Forming Networks (PFN).
Key requirements for this application include:
• High voltage operation (50kV)
• Continuous operation at >10 Hz
• Stable and repeatable charging performance
• Robustness and long-term reliability
• Custom interfaces compatible with existing control and safety systems
More than 10 years after installation, these systems are still operating reliably.
Based on this performance, Technix has recently been selected to supply two additional chargers, to extend the facility’s capabilities while ensuring full compatibility with the existing setup.
This is a great example of long-term reliability on a highly specific and demanding application. 💡
#HighVoltage #PulsedPower #CapacitorCharger #Synchrotron #Research #Engineering
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
In semiconductor manufacturing, improving silicon quality is a constant challenge. One of the key technologies used today is Excimer Laser Annealing.
This process relies on pulsed UV lasers to locally treat silicon without affecting the rest of the wafer.
Behind this technology lies a critical component: the pulsed plasma used to generate UV light. This is where Technix capacitor chargers play a key role.
Requirements for this application include:
• ~30kV output voltage
• Up to 500 mA charging current
• Pulse-to-pulse reproducibility
• Reliability and robustness
• Remote control interfaces compatible with various systems
For nearly 18 years, Technix has been supplying chargers for this demanding application. Our customers’ continued trust reflects not only product performance, but also long-term reliability and support.
This is one example of our expertise across multiple high-power pulsed laser applications, where precision and consistency are essential. 💡
#PulsedLaser #Semiconductor #LaserTechnology #HighVoltage #PowerSupply #CapacitorCharger #Engineering #Innovation
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
Subsea environments place extreme demands on electrical systems. High-voltage power supplies play a key role in two main applications:
🔌 𝐒𝐮𝐛𝐬𝐞𝐚 𝐜𝐚𝐛𝐥𝐞 𝐭𝐞𝐬𝐭𝐢𝐧𝐠
High voltage (typically 30 to 50kV) is injected to measure leakage current and verify cable isolation.
→ With our zero-floating option, users can directly measure output current with high precision — without floating the equipment under test.
Technix also supports customers in defining the most accurate and adapted solution for their specific setup.
🌐 𝐏𝐨𝐰𝐞𝐫𝐢𝐧𝐠 𝐬𝐮𝐛𝐬𝐞𝐚 𝐟𝐢𝐛𝐞𝐫 𝐨𝐩𝐭𝐢𝐜 𝐫𝐞𝐩𝐞𝐚𝐭𝐞𝐫𝐬
Modern installations rely on HV lines (typically 5 to 10kV, with currents of a few amps) to power repeaters in series over long distances.
→ Installed offshore, the power system must be highly reliable and easy to integrate.
Our solutions are ideally suited for Power Feed Equipment (PFE) applications, offering:
• Proven robustness in demanding environments
• Flexible control interfaces
• Seamless integration with various control systems
These are mission-critical applications where performance alone is not enough — customers also rely on strong technical support and long-term partnership. Technix combines both. 🤝
#Subsea #HighVoltage #PowerSupply #CableTesting #FiberOptics #Offshore #Engineering #Energy
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
Protontherapy is an advanced cancer treatment that relies on cyclotrons and synchrotrons to generate a precise and controlled proton beam.
Several key functions depend on reliable high-voltage power supplies to ensure performance and stability.
Technix HV power supplies support:
• Ion sources
• Acceleration, deflection & extraction electrodes
• Grids (which can be isolated at high voltage)
• Filaments isolated at high voltage
• Pulsed power systems
Technix provides robust and precise HV solutions to support the development of cutting-edge proton therapy systems.
Empowering innovation in cancer treatment, one component at a time. ⚡
#ProtonTherapy #CancerTreatment #MedicalTechnology #HighVoltage #PowerSupply #Accelerators
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
Technix keeps pushing development further.
Our teams have just completed a 60kV – 6kW power supply designed for X-Ray scanning, now entering its final qualification phase.
What’s new?
• Integrated cathode power supply
• Extended operating range with 6kW available from 50kV to 60kV
• Highly compact design in a 5U 19” rack
• Air-cooled for simple and efficient integration
This second prototype brings Technix one step closer to production and we’re proud of the work accomplished by everyone involved.
More updates coming soon!
#XRayScanning #PowerSupply #HighVoltage #Engineering #Innovation
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
For a renowned particle accelerator in Asia, Technix has delivered two types of DC power supplies dedicated to an electrostatic separator:
→ 40 kV – 10 kW: 2 units
→ 25 kV – 8 kW: 2 units
To meet the customer’s demanding specifications, the following options were implemented by Technix:
→ Ultra-low ripple
→ Advanced arc management
→ Digital remote control via optical fiber
→ Custom analogue interface fully compatible with the existing control system
Technix is proud to contribute to cutting-edge research by delivering high-performance power solutions tailored to the most complex scientific applications.
#HighVoltage #PowerSupplies #ParticleAccelerator #ElectrostaticSeparator #Innovation #Engineering
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
We are proud to announce the successful manufacturing of a 50kV – 120kW DC power supply specifically designed to meet the demanding requirements of gyrotron cathodes.
This custom-built system was engineered with the unique constraints of gyrotron tubes in mind, delivering:
• Fast rise time
• Low stored energy to enhance protection
• Fast inhibit input for immediate shutdown when required
• Optimized arc protection ensuring safe and reliable operation
Delivered in a modular architecture, it enables easy servicing and smooth integration into customer 19″ cabinets.
The complete system includes:
• 6 × 50kV – 20kW 5U 19″ modules
• A HV interconnection rack for parallelized HV outputs
• All interface cables for plug-and-play installation
This development represents a major step forward in our contribution to high-performance, dependable power solutions for gyrotrons and fusion research.
Next milestone coming soon: 50kV – 240kW DC power supplies for gyrotrons! 👏
#Gyrotron #PowerSupply #NuclearFusion #HighVoltage #EngineeringInnovation #EnergyResearch #FusionTech
Discover more news about Technix on our LinkedIn page : https://www.linkedin.com/company/technix-hv/
Technix pushes the limits of capacitor charging with its 45kV-14kJ/s high-power charger, designed specifically for pulsed power systems.
Key features:
→ Controlled peak output power up to 20 kW with optimized charging current
→ High operating frequency 100 Hz at full voltage and energy
→ Exceptional power density all packed into a 5U 19” rack
→ Air-cooled for simplified maintenance
→ Customized HV connectors and cables
→ Automatic inhibition of HV output when the capacitor is discharged
Whether you’re developing advanced pulsed power systems or need a compact, high-performance solution, our charger delivers power, reliability, and safety.
#HighVoltage #CapacitorCharger #Engineering #PowerElectronics #HighFrequency #R&D
